FD-LTR200 Linear OPP Labeling Machine
Production Capacity: 5000-12000 bottles per hour
Operation Model: Fully-automatic hot glue labeling machine
Label Material: OPP label, BOPP label
Suitable Bottle: Glass bottle, PET bottle, Metal Bottle
Benefit of FESTA FD-LTR200 Full-auto Hot Glue Labeling Machine
Linear OPP hot melt glue adhesive labeling machine is the newest continuous operation of the OPP labeling machine. The mainly used for container labeling cylindrical shape of detergents, beverages, mineral water, food etc. The material of label is using environmentally material of OPP films. It can be automatically oxidative decomposition and reduce production costs by more than 30 percent. Our OPP labeler is control by PLC touch screen, all electric eye is using imported advanced configuration. This labeling machine with high speed, high accuracy, stable performance, easy to operate and look elegant appearance.
- Body is built with stainless steel, steel construction stable and not rust.
- The whole machine used quick release type of construction. In order to change and adjustment easier.
- Centralized lubricating system for simple and effortless on maintenance, lubrication and cleanness
- With photo-sensors to detect label output and automatically self-regulated production speed for integrating production line with other machines
- Used stable and reasonable of compiling program. It can be suitable for operation 24 hours.
- The bottle working mode is linear Input and output type.
- Equipped with the Torque limiter would control the torsion range abnormal situation of machine. It will reduce the accident for operate.
- Roller coating, gluing balance and glue saving.
- Alarm system: Caution light & buzzer for out of label, Label break and door open!
- Label cutting system: Used multiple cure of cut system organization. (It is not quick-wear part)
- The machine production speed is control by the machine input bottle signal. It is automatic transmission. If input bottle stock, then the machine will be increase speed. If input bottle did not have bottle the machine will transmission speed slow.
- The machine production speed is control by the machine input bottle signal. It is automatic transmission. When the machine output bottle stock then the machine will be transmission speed to slow. If output bottle is smooth the machine will be increasing the speed.
Model | FD-LRT200 |
Machine size | 2636L*1500W*2050H(mm) |
Weight | 2.5 ton |
Speed of labeling | 3000BPH-8000BPH |
Power | AC 3ψ380V50Hz |
Rater power | 10KW |
Percent of pass | ≥99.5 |
Accuracy of labeling | ±1mm |
Diameter of bottle | 40-90mm |
Material of bottle | Glass, Metal, Plastic |
Shape | Round |
Label material | OPP label, BOPP label |
Label thickness | 0.035-0.05mm |
Label height | 40mm-140mm |
Inside diameter of paper tube | 6inch |
Power consumption of air source | 0.5Mpa |
Operation | Automatically |
