Automatic 5 Gallon & 20L Bagging Machine
Production Capacity: 600-1200BPH
Main Material: Stainless steel
Control Mode: Auto control
Suitable Bottle: 4-5 gallon barrel
Technical Features of FESTA TD-1200 5 Gallon Film Bagging Machine
- The 5-gallon film bagging machine uses 2mm stainless steel laser cutting and bending, ensuring high processing precision, stable operation, and an attractive appearance.
- It employs a Japanese Mitsubishi PLC controller, a German Siemens contactor, a Taiwanese Weinview touch screen, and imported electrical components, ensuring stable operation and durability.
- It utilizes frequency conversion control, resulting in low soft-start current, effectively protecting electrical components and saving energy.
Video
Description
The fully automatic 20-liter bagging equipment uses a DuPont Teflon-coated, non-stick, high-temperature resistant aluminum alloy blade for sealing, ensuring a crack-free, non-charring, smokeless, and pollution-free seal. The equipment is equipped with imported photoelectric sensors, one set each for horizontal and vertical detection, allowing for easy switching and selection. It can easily seal and package thin and small items. Automatic feeding and length adjustment via a combination of photoelectric sensors and timers make adjustments very simple when packaging dimensions change, without needing to change molds or bag makers. It uses an original imported digital display temperature controller with PID function, ensuring extremely sensitive and precise sealing temperature settings. There’s no need to worry about inaccurate temperature or product defects; the sealing knife itself has an automatic protection function to effectively prevent accidental cutting of the packaged goods. The entire machine truly achieves unmanned operation when connected to the production line. A specially designed film synchronization mechanism corrects film misalignment.
Data Sheet
Machine Model | TD-1200 |
Production Capacity | 600-1200BPH |
Suitable Container | 5 gallon bottle, 19liter bottle, 20liter bottle |
Film raw material | PE |
Film thickness | Double layer 0.01mm-0.02mm |
Film width | Double layer 700mm |
Power | 1.5KW |
Dimensions | 2000×1500×1600mm |
Weight | 400kg |
FAQ
Finished water buckets enter the conveyor chain of a fully automatic 5-gallon film bagging machine. The conveyor motor drives the chain to send the bucket into the bagging mechanism. The plastic film is opened by the opening mechanism. As the bucket passes through the bagging mechanism, the plastic film wraps around the bucket. The cutter cuts off the excess plastic film and heat seals it. After the plastic film is sealed, it is fixed on the outer surface of the bucket. After the bagging process is completed, the bucket is sent into the conveyor chain or roller conveyor.
It can save water companies 2-3 workers for bagging, saving $20,000 in labor costs annually; compared with traditional bagged membranes, it can save 20% per barrel, saving $15,000 in membrane costs annually;
The TD series fully automatic 5-gallon film bagging machine consists of a frame, barrel feeding mechanism, sealing and cutting mechanism, film dragging mechanism, and electrical control system. It works in conjunction with a conveyor system to achieve online assembly line operation. The entire machine is constructed of high-quality stainless steel, which is corrosion-resistant and easy to clean. Major electrical components are all imported. This machine features an attractive appearance, compact structure, high efficiency, stable and reliable operation, and a high degree of automation. It is an ideal accessory for fully automatic barrel bottling production lines with integrated servo motors.
